CONTREX CX-1200 - Manual (Page 479)

J - 2
Appendix J: Default PLC Program Logic (continued)
PLC Command Equivalent Logic Ladder
LOAD 89 Rvs Cmd
OUT 106 DO_6
LOAD 66 LdSyncMis
OUT 103 DO_3
Rvs Cmd
89
DO_6
106
LOAD 67 FbSyncMis
OUT 104 DO_4
LdSyncMis
66
DO_3
103
LOAD 29 HiSpdAlm
OR 28 LoSpdAlm
OUT 101 DO_1
FbSyncMis
67
DO_4
104
HiSpdAlm
29
DO_1
101
LOAD 51 DrvEnable
OUT 107 DO_7
LOAD 32 Cntr 1 Out
OUT 105 DO_5
DrvEnable
51
DO_7
107
LOAD 65 OutOfPosn
OUT 102 DO_2
Cntr 1 Out
32
DO_5
105
OutOfPosn
61
DO_2
102
LoSpdAlm
28
LOAD 53 RR@0Spd
AND 54 FB@0Spd
OUT 100 DO_0
RR@0Spd
53
DO_0
100
Fb@0Spd
54
