AASTRA 6700i series, 9143, 9480i, 9480i CT SIP Administrator Guide EN - Manual (Page 772)

41-001343-01 Rev 03, Release 3.2.2 A-41
Virtual Local Area Network (VLAN) Settings
Global Parameters
LAN Port (Ethernet Port 0) Parameters
Parameter –
tagging enabled
VLAN Enable
(in Web UI)
IP phone UI Options->Administrator Menu->
Network Settings->VLAN->VLAN Enable
Aastra Web UI Advanced Settings->Network->VLAN->Global
Configuration Files aastra.cfg, .cfg, .cfg
Description Enables or disables VLAN on the IP phones. This is a global setting.
Format Boolean
Default Value 0 (false)
Range 0 (false)
1 (true)
Example tagging enabled: 1
Parameter –
priority non-ip
Priority, Non-IP Packet
(in Web UI)
IP phone UI Options->Administrator Menu->
Network Settings->VLAN->Phone->Priority
->Other
Aastra Web UI Advanced Settings->Network->VLAN->Global
Configuration Files aastra.cfg, .cfg, .cfg
Description Specifies the priority value for non-IP packets. This is a global setting.
Format Integer
Default Value 5
Range 0 to 7
Example priority non-ip: 7
Parameter –
vlan id
VLAN ID
(for LAN Port in
Web UI)
IP phone UI Options->Administrator Menu->
Network Settings->VLAN->Phone->VLAN ID
Aastra Web UI Advanced Settings->Network->VLAN->Port 0
Configuration Files aastra.cfg, .cfg, .cfg
Description VLAN is a feature on the IP phone that allows for multiple logical Ethernet
interfaces to send outgoing RTP packets over a single physical Ethernet
as described in IEEE Std 802.3. On the IP phone, you configure a VLAN
ID that associates with the physical Ethernet Port 0.
Format Integer
Default Value 1
Range 1 to 4094
Example vlan id: 300
