AASTRA 6700i series, 9143, 9480i, 9480i CT SIP Administrator Guide EN User Manual
Page 495

5-218
41-001343-01 Rev 03, Release 3.2.2
• On the Model CTs, the customized labels apply to the base unit only. On the Model CT
handsets, pressing the Features key displays the default labels of "Park" and "Pickup".
On 3-Line LCD Phone UIs
• When a call comes in, and you pickup the handset, you can press the applicable "Park"
programmable key to park the call.
• After the call is parked, you can press the "Pickup" programmable key, followed by the
applicable value to pickup the call.
Configuring Park/Pickup Key Using Configuration Files
In the configuration files, you configure the park/pickup keys using the key parameters. You also
must specify the "sip lineN park and pickup config” parameter. The following examples show
park/pickup configurations using specific servers.
Examples for Models with 8 and 11-Line LCDs
*When you configure a softkey as "Park", you must configure the state of the softkey as "connected".
**When you configure a softkey as "Pickup", you can configure the state of the softkey as "idle, outgoing", or just
"idle", or just "outgoing".
Examples
for Models with 3-Line LCDs
Note:
On the 9480i/9480i CT and 6757i/6757i CT, the old softkey
labeled "Pickup" has been renamed to "Answer". This softkey uses the
old functionality - when you pickup the handset, you see a softkey labeled
"Answer". You can then press this key to pick up an incoming call. Do no
confuse this feature with the new Park/Pickup configuration feature.
Server
Park Configuration
Pickup Configuration
Asterisk
softkeyN type: park
softkeyN label: parkCall
softkeyN states: connected*
sip lineN park pickup config: 70;70;asterisk
softkeyN type: pickup
softkeyN label: pickupCall
softkeyN states: idle, outgoing**
sip lineN park pickup config: 70;70;asterisk
Sylantro
softkeyN type: park
softkeyN label: parkCall
softkeyN states: connected*
sip lineN park pickup config:*98;*99;sylantro
softkeyN type: pickup
softkeyN label: pickupCall
softkeyN states: idle, outgoing**
sip lineN park pickup config: *98;*99;sylantro
BroadWorks
softkeyN type: park
softkeyN label: parkCall
softkeyN states: connected*
sip lineN park pickup config:*68;*88;broadworks
softkeyN type: pickup
softkeyN label: pickupCall
softkeyN states: idle, outgoing**
sip lineN park pickup config: *68;*88;broadworks
Server
Park Configuration
Pickup Configuration
Asterisk
prgkeyN type: park
sip lineN park pickup config: 70;70;asterisk
prgkeyN type: pickup
sip lineN park pickup config: 70;70;asterisk
Sylantro
prgkeyN type: park
sip lineN park pickup config: *98;*99;sylantro
prgkeyN type: pickup
sip lineN park pickup config: *98;*99;sylantro
BroadWorks
prgkeyN type: park
sip lineN park pickup config: *68;*88;broadworks
prgkeyN type: pickup
sip lineN park pickup config: *68;*88;broadworks
