3-46 41-001343-01 Rev 03, Release 3.2.2
PC Port Settings (Port 1)
PC Port VLAN ID
VLAN ID VLAN id port 1 Specifies the VLAN ID used to pass packets
through to a PC via Port 1.
Note: If you set the PC Port VLAN ID (Port 1) to
4095, all untagged packets are sent to this port.
The following is an example of configuring the
phone on a VLAN where all untagged packets are
sent to the passthrough port.
Example
You enable tagging on the LAN Port (VLAN id) as
normal but set the PC Port (VLAN id port 1) to
4095. The following example sets the phone to be
on VLAN 3 on the LAN Port but the PC Port is
configured as untagged.
tagging enabled: 1
VLAN id: 3
VLAN id port 1: 4095
For more information, see Chapter 4,
“Virtual LAN
(optional)” on page 4-51 .
Note: The PC Port parameters are not applicable
to the 6730i IP Phone.
PC Port Priority Priority QoS eth port 1 priority Specifies the priority value used for passing VLAN
packets through to a PC via Port 1.
For more information, see Chapter 4, “Virtual LAN
(optional)” on page 4-51 .
Parameter In
IP Phone UI
Parameter in
Aastra Web UI
Parameters in
Configuration Files
Description
