Call Park/Pickup Configuration Precedence Rule

For users upgrading from Release 2.x firmware, the "softkeyN value" parameter will be used if

the "sip lineN park pickup config" parameter is not set. If the per-line park pickup config

parameter is set, the following precedence rule will apply:

"sip lineN park pickup config: ;;

broadworks>" will override

"sip park pickup config: ; ; "

"sip park pickup config: ;;"

will override

"softkeyN value: " (or topsoftkeyN, prgkeyN, or expmod1 keyN).

"softkeyN value: ;"

will have lowest priority.

For example, the following has been configured on the phone:

softkey1 type: park

softkey1 label: parkCall

softkey1 states: connected

softkey1 value: broadworks;*68

softkey2 type: pickup

softkey2 label: pickupCall

softkey2 states: idle, outgoing

softkey2 value: broadworks;*88

sip park pickup config: 70;70;asterisk

sip line1 park pickup config: *78;*98;broadworks

If the active call is using Line1, the phone will use the BroadWorks method for park (*78) and

pickup (*98) since per-line has the highest precedence.

If the active call is using any other line except Line1, the phone will use the Asterisk method for

park (70) and pickup (70) since it has precedence over the softkey value.

Note:

The 6730i, 6731i, 6735i, 6737i, 6753i, 6755i and 9143i do not

allow for the configuration of labels and states for programmable keys.

Note:

This feature is not supported on 6735i and 6737i IP phones for

Release 3.2.2.

Configuration Files

For specific parameters you can set in the configuration files, see Appendix A, the section,

and
