41-001343-01 Rev 03, Release 3.2.2
5-103
The following table identifies the configuration parameters for LLDP and ELIN and which method
you can use to configure each parameter. This table also indicates whether the parameters can be
configured by an Administrator, a User, or both.
Configuring LLDP-MED and ELIN
Use the following procedures to configure LLDP-MED and ELIN on the IP phones.
Use the following procedure to enable/disable LLDP-MED using the IP Phone UI.
Parameter
Method of Configuration
Who Can Configure
lldp
Configuration Files
Administrator
lldp interval
Configuration Files
Administrator
use lldp elin
Configuration Files
Administrator
lldp startinterval
Configuration Files
Administrator
LLDP Support
IP Phone UI
Administrator
LLDP
Aastra Web UI
Administrator
LLDP Packet Interval
Aastra Web UI
Administrator
LLDP ELIN
Aastra Web UI
Administrator and User
Configuration Files
For specific parameters you can set in the configuration files, see Appendix A, the section,
Note:
You cannot configure the “LLDP Interval” or the “Use LLDP
ELIN” parameters via the IP Phone UI.
Aastra IP Phone UI
Step
Action
1
Press Options, and then select Administrator Menu.
2
Select Network Settings.
3
Select Ethernet & VLAN.
4
Select LLDP Support.
