41-001343-01 Rev 03, Release 3.2.2 4-23
Configuring Network Settings Manually
If you disable DHCP on your phone, you need to configure the following network settings
manually:
• IP Address
• Subnet Mask
• Gateway
• Primary DNS
• Secondary DNS
You can configure the network settings using the configuration files, the IP phone UI, or the Aastra
Web UI.
Errors Messages Display when Incorrect Network Settings Entered
The IP Phone UI AND the Aastra Web UI immediately notify the Administrator if an incorrect
value is being entered for the following network parameters in the IP Phone UI and the Aastra Web
UI. :
• A 0.0.0.0 entered as values for the IP Address, Subnet Mask and Gateway parameters
• IP Address and Gateway IP address parameter values entered exactly the same
• Gateway IP address and the IP address parameter values configured on the same subnet
If you configure the Gateway parameter and the IP Address parameter on the same subnet, the
following error message displays:
“Gateway IP address and the IP address parameter values configured are not on the same subnet”.
Note: If you disable DHCP on the phone, the phone uses the TFTP
protocol as the default server protocol. If you want to specify a different
protocol to use, see “Configuration Server Protocol” on page 4-104 .
Configuration Files
For specific parameters you can set in the configuration files, see Appendix A, the section, “Network
Settings” on page A-8.
