41-001343-01 Rev 03, Release 3.2.2

5-135

5

Click on Operation->Softkeys and XML
or
Click on Operation->Programmable Keys
or
Click on Operation->Expansion Module .

Note: Depending on your phone-model, the key configuration screen displays. The 6757i Key
Screen is shown as an example.

6

Select a softkey or programmable key to configure.

7

In the "Type" field, select "XML”.

8

For 8 and 11-Line LCD softkeys:

In the "Label" field, enter the name of the person who’s extension you are monitoring.

9

In the "Value" field, enter the URI that the phone uses to display the XML application to the LCD.
For example, http://65.205.71.13/xml/startup/key.php?user=$$SIPREMOTENUMBER$$.

Note: For more information about creating an XML script to use with Directed Call Pickup, see the
Aastra XML Developer’s Guide

.

10

Select the line state (idle, connected, incoming, outgoing, busy) that you want to apply to the XML
softkey or programmable key.

11

Click

to save your changes.

Aastra Web UI
