PROGRAM STEPS
MILLPWR ®
Operation Manual 5-60
Step Functions Softkey
Additional functions are available from the PGM screen by pressing the STEP
FUNCTIONS softkey.
Explode
This feature will "explode" a program step into several,
more detailed steps. You can explode the following func-
tions:
• All "Holes" functions (row, frame, array and bolt circle)
• Repeat, Mirror and Rotate
• Engrave
In the example on the right, a bolthole circle with eight holes
has been programmed. Now use the same basic
pattern, but with seven holes.
To edit the program, first highlight the “Bolt
Circle” step and then press the
EXPLODE softkey.
