analyzer display 757
✓ 3500
✓ 9000
✓ 9400
✓
3900
✓
9300
analyzer display Displays the roving analysis configuration, showing which ports are
designated as analyzer ports and which bridge ports are currently being
monitored.
Valid Minimum Abbreviation
an d
Fields in the Analyzer Display
Analyzer Display Example (3500)
Field Description
Ports configured as
analyzer ports List of analyzer ports on the system, including the port
number and MAC address. These are the ports that can
accept traffic that is mirrored from a monitored port.
Analyzer ports are typically connected to a network
analyzer or probe. There may be multiple analyzer ports
defined on the switch.
Port Analyzer port number
Type Media type and Port Speed ( FDDI , Fast Ethernet , or
Gigabit Ethernet )
Address MAC address of the analyzer port
Ports being monitored List of ports that the system is monitoring. Includes the
MAC address of the analyzer port to which the monitored
port traffic will be forwarded.
Port Monitored port number
Type Media type and Port Speed ( FDDI , Fast Ethernet , or
Gigabit Ethernet )
Analyzer Address MAC address of the analyzer port to which the monitored
port traffic will be forwarded and to which your network
analyzer or probe is attached. There may be multiple
analyzer ports defined on the switch.
Select menu option (analyzer): display
Ports configured as analyzer ports:
Port Type Address
8 Fast Ethernet 00-80-3e-2b-42-08
Ports being monitored:
Port Type Analyzer Address
12 Fast Ethernet 00-80-3e-2b-42-08
