708 C HAPTER 22: Q UALITY OF S ERVICE (Q O S) AND RSVP
✓ 3500
✓ 9000
9400
3900
9300
qos control detail For CoreBuilder 9000: Applies to Layer 3 switching modules only.
Displays detailed information about the QoS controls that you specify.
Valid Minimum Abbreviation
q co det
Options
Fields in the QoS Control Detail Display
Prompt Description Possible Values [Default]
Control
number Number of the control for
which you want detail
information
■
One or more
configured
controls
■
all
■
? (for a list of
selectable
controls)
–
Field Description
802.1p tag IEEE 802.1p priority tag value ( 0 – 7) that is applied to
forwarded frames. Can be defined for both flow and
nonflow classifiers.
Burst Burst size in KBytes.
Classifiers controlled Classifiers that this control affects.
Control (number) Number of the control.
Control name Name that you assign to the control.
End time Control end time.
Excess loss eligible For receivePort or aggregate rate limit types, whether excess
packets are loss eligible.
Excess service For receivePort or aggregate rate limit type, service level for
excess packets.
Limit Rate limit in KBytes/sec or percentage.
Loss eligible Whether conforming packets are loss eligible. A loss-eligible
packet can be dropped if the transmit queue for which it is
destined is over its threshold.
Ports Receive ports for which you want to enable the rate limit.
Rate limits control Number of the control that the rate limit affects.
Service Service level for the conforming packets ( high , best , low ,
or drop ).
