702 C HAPTER 22: Q UALITY OF S ERVICE (Q O S) AND RSVP
Protocol type IP or other protocol
type, if applicable, that
is associated with the
flow or nonflow
classifier.
■
Flow classifiers: IP
protocol type with
TCP, UDP, or all
■
Nonflow classifiers:
TCP, IP, IPX,
AppleTalk, any, or
custom
■
? (for a list of
selectable values)
Current
protocol
type
Source IP
address For flow classifiers only,
IP address of the source. Up to 255.255.255.255 0.0.0.0
(factory
default,
wildcard
match), or
current
value
Source IP
address mask For flow classifiers only,
source IP address mask,
or how many portions of
the IP address you want
to match. (Example:
255.255.255.0 matches
the first three portions
of the specified IP
address.) Up to four portions
(255.255.255.255) 0.0.0.0
(factory
default,
wildcard
match), or
current
value
Destination IP
address For flow classifiers only,
destination IP address. Up to 255.255.255.255 0.0.0.0
(factory
default), or
current
value
Destination IP
address mask For flow classifiers only,
destination IP address
mask, or how many
portions of the IP
address you want to
match. Up to four portions
(255.255.255.255) 0.0.0.0
(factory
default), or
current
value
Start and end
of TCP or UDP
source port
range For flow classifiers only,
start and end of the TCP
or UDP source port
range.
Specify as small a range
as possible. The start
value determines the
end value.
0 – 65535 0 and
65535
(factory
defaults),
or current
values
Prompt Description Possible Values [Default]
