management summary 151
management
✓
3500
9000
✓
9400
3900
✓ 9300
summary
Displays Ethernet summary information about the out-of-band system
management port.
Valid Minimum Abbreviation
m sum
Important Considerations
■
The management summary and management detail displays contain
the same fields as the Ethernet
summary
and Ethernet
detail
displays.
■
Fields that do not apply to the management port contain n/a in the
management summary and management detail displays.
Fields in the Management Summary Display
Field Description
actualFlowControl Actual flow control setting (for Gigabit Ethernet ports).
When autonegotiation is completed, the value is the
autonegotiated setting. When autonegotiation is
disabled, the value is the user-selected flow control value.
actualPortMode Actual operating port mode. When autonegotiation is
completed, the value shown is the autonegotiated setting.
When autonegotiation is disabled, the value is the
user-selected port mode.
autoNegMode Autonegotiation mode configured for port. Possible
values are
enabled or disabled .
autoNegState Current negotiation state. Possible values are disabled ,
configuring , completed , and failed .
linkStatus Boolean value indicating the current state of the physical
link status for this port (either
enabled or disabled )
macAddress MAC address of this port
noRxBuffers Number of frames that were discarded because no buffer
space was available
portLabel User-defined label name. The maximum length of the
string is 32 characters, including the null terminator.
portState Current software operational state of this port. Possible
values are
on-line and off-line .
portType Specific description of this port’s type. Value for port type:
10/100BASE-TX (RJ-45)
reqFlowControl If autonegotiation is disabled, a configurable parameter
that sets the flow control option on the ports. If
autonegotiation is enabled, flow control values are
ignored.
