qos control define 715
Procedure
1 Enter a control number.
The valid range is 5 through 50 , with the next available number as the
default.
2 Enter a control name.
3 Enter the rate limit type: none , receivePort , or aggregate .
The default is none . To drop all conforming packets for a set of ports, use
receivePort or aggregate , set the rate limit to 0 , and specify the
appropriate set of ports.
You can apply aggregate rate limits only to flow classifiers.
4 For the receivePort or aggregate limit type, enter the service level
for conforming packets as high , best , or low .
For the none rate limit type, enter the service level for conforming
packets as high , best , low , or drop .
The default is best (best effort).
If you use drop , the system drops all traffic on all ports for the classifier
that is associated with the control. Ping packets are ICMP, not UDP/TCP, so
they are not dropped.
5 Specify whether the conforming packets are loss eligible ( yes or no) .
The default is no .
6 If you have selected receivePort or aggregate for the rate limit
type, you are prompted for the following information:
a Enter the service level for excess packets ( high , best , low , or drop ).
The default is best .
b Specify whether excess packets are loss eligible ( yes or no ).The
default is yes .
c Specify how the rate limit is expressed ( percentage of port
bandwidth or KBytes/sec . KBytes/sec is the default.
Every weekday Starting time (hh:mm)
Ending time (hh:mm)
Every weekend Starting time (hh:mm)
Ending time (hh:mm)
Input Time Type Options
