3Com 3500 - Manual (Page 731)

qos rsvp enable 731
Procedure
1 Enter the maximum total reservable bandwidth, using a percentage of
the output link (a value of from 0 through 200 , with 50 as the default).
2 Enter the maximum per-reservation bandwidth, using a percentage of the
output link (a value of from 0 through 100 , with 50 as the default).
3 Enter the policing option ( edge , always , or never , with edge as the
default).
4 Enter the service level for excess/policed traffic ( best or low , with low
as the default).
5 Specify whether excess packets are loss eligible ( yes or no , with no as
the default).
Service level
for excess
/policed traffic Service level for excess/policed
traffic. Low is recommended.
This setting applies to the
excess traffic with the reserved
bandwidth (that is, which
queue it should be placed in).
■
best
■
low
low (factory
default)
Excess Loss
Eligible Whether excess packets are
loss-eligible
■
yes
■
no
no (factory
default)
Prompt Description Possible Values [Default]
