qos classifier detail 693
Classifier – Filters
(flow classifiers only) Filters (address and port patterns):
■
Source IP address
■
Source IP address mask
■
Destination IP address
■
Destination IP address mask
■
Transmission Control Protocol (TCP) or User Datagram
Protocol (UDP) port range
Destination Port range
(flow classifiers only) Beginning and end of the TCP or UDP destination port
range
Source Port range
(flow classifiers only) Beginning and end of the TCP or UDP source port range
Classifier – Installed
Flows (if flows exist) Actual flows seen on the system, with the following data:
■
Port
■
Source IP address/source port
■
Destination IP address /destination port
■
Protocol type
■
Number of flow cache misses
Control Control number that you assign to the control
Name Name that you assign to the classifier
Protocol Protocol type, if applicable, that is associated with the
classifier and control
Field Description
