Displaying PPP Entity Status
Page 30-19
BCP Oper State
Indicates the operational state of the Bridging Control Protocol option.
Open
means that the
bridging operation is active.
Closed
means that the bridging operation has not yet reached the
open state. The reasons why the state may be closed are: 1) the call has been disconnected,
2) the protocol is in the process of making a connection, or 3) the Bridging option was not
configured.
CCP Oper State
The operational state of the compression control protocol option.
Open
means that
compression is active.
Closed
means that compression has not reached the open state. The
reasons why the state may be closed are: 1) the call has been disconnected, 2) the protocol is
in the process of making a connection, or 3) the compression option was not configured.
Displaying the Status of a Specific PPP Entity
To view both the operational status and the relevant statistics of a specific PPP Entity, for
example, Peer ID 1, enter the following command:
pppstatus p1
A screen similar to the following displays:
PPP statistics for Peer ID: 2
IP
IPX
BCP
CCP
Admin
Oper
Oper
Oper
Oper
State
Mode
State
State
State
State
======
======
======
======
======
=======
UP
Normal
Open
Close
Open
Close
LCP Pkts
IPCP Pkts IPCP Pkts BCP Pkts
CCP Pkts
IN/OUT
IN/OUT
IN/OUT
IN/OUT
IN/OUT
=======
========
=======
======== =========
3/4
2/2
0/0
4/4
0/0
Packets Packets Packets Octets
Octets
In
Out
In+Out
In
Out
%In
%Out
======= ======= ======= ======= ======= ==== =====
Total
2232
1475
3707
91751
66034
Ethernet
0
146
146
0
13413
0
20
8025
0
0
0
0
0
0
0
FDDI
0
0
0
0
0
0
0
IP
79
158
237
7784
6952
8
10
IPX
0
0
0
0
0
0
0
BPDU
2153
1171
3324
83967
45669
91
69
STAC-LZS
Compressed
Compressed
Uncompressed
Compression
Compression
Frames
Octets
Octets
Ratio
===========
===========
============
===========
In
0
0
0
0.0:1
Out
0
0
0
0.0:1
IN+Out
0
0
0
0.0:1
The additional fields produced by the
pppstatus
command when a specific Peer ID is entered
with the command are as follows:
LCP Pkts IN/OUT
The total number of Link Control Protocol (LCP) packets received (
In
) and transmitted (
Out
)
on this PPP connection.
