Viewing T1 Remote Statistics
Page 33-21
Viewing Current Remote Statistics
You can view remote statistics for the current 15-minute interval on a single port by entering
the following command
tercs /
where is the slot number where the board is located, and is the port number on
the board on which you want to view statistics. For example, to view remote 15-minute inter-
val statistics for Port 2 on the board in slot 5, enter
tercs 5/2
A screen similar to the following displays:
Remote Current 15-minute Measurement for port 2 on slot 5
Circuit Identifier
: Alcatel T1 Circuit
Valid Intervals : 1 of 96 Elapsed Time : 1 of 900
ES SES BES UAS DM SEFS LES CSS PCV LOFC
====== ====== ====== ====== ====== ====== ====== ====== ====== ======
0 0 0 0 0 0 0 0 0 0
Definitions of the fields and columns in this display are the same as those used for the telts
command. See Viewing Total Local Statistics on page 33-17 for an explanation of these statis-
tics.
Viewing Remote Historical Statistics
The teris command allows you to display remote historical statistics for the past 96 15-minute
intervals. Enter the following command
teris /
where is the slot number where the board is located, and is the port number on
the board on which you want to view statistics. For example, to view remote historical 15-
minute interval statistics for Port 2 on the board in slot 5, enter
teris 5/2
A screen similar to the following displays:
Remote 15-minute Interval Statistics for port 2 on slot 5
Circuit Identifier : Alcatel T1 Circuit
Valid Intervals : 5 of 96 Elapsed Time : 25 of 900
Intv# ES SES BES UAS DM SEFS LES CSS PCV LOFC
===== ====== ====== ====== ====== ====== ====== ====== ====== ====== ======
1 0 0 0 0 0 0 0 0 0 0
2 0 0 0 0 0 0 0 0 0 0
3 0 0 0 0 0 0 0 0 0 0
4 0 0 0 0 0 0 0 0 0 0
5 0 0 0 0 0 0 0 0 0 0
Definitions of the fields and columns in this display are the same as those used for the telts
command. See Viewing Total Local Statistics on page 33-17 for an explanation of these statis-
tics.
