Auto-Sensing 10/100 Ethernet Modules
Page 3-17
ESX-K-100C-32W Technical Specifications
Number of ports
32
Connector Type
RJ-45
Standards Supported
IEEE 802.3; IAB RFCs 826, 894
Data Rate
10 or 100 Mbps (full or half duplex)
Maximum Frame Size
1,518 bytes
MAC Addresses Supported
ESX-K-100C-32W: 1,024
ESX-K-100C-32W4: 4,096
Connections Supported
10BaseT hub or device
100BaseTx hub or device
Cable Supported
10BaseT
Unshielded twisted-pair (UTP)
100BaseTx
Unshielded twisted-pair:
Category 5, EIA/TIA 568
Shielded twisted-pair
Category 5, 100 ohm
Maximum Cable Distance
100 m
Current Draw
10.25 amps without an HRE-X
11.75 amps with an HRE-X
