HEIDENHAIN TNC 406, TNC 416 95
6.4 P
ath Cont
ours — Car
tesian Coor
dinat
es
Programming a straight line
Example — programming a straight line:
Initiate the programming dialog, e.g. for a straight
line.
Enter the coordinates of the straight-line end point.
Select the radius compensation (here, press the RL
soft key - the tool moves to the left of the
programmed contour).
Move the electrode on the straight line directly to the
end point
Enter the feed rate (here, 100 mm/min), and confirm
your entry with ENT.
Choose rapid traverse for the electrode:
F = F MAX
Enter a miscellaneous function, for example M37
(Eroding OFF).
The part program now contains the following line:
COORDINATES ?
RADIUS COMP. RL/RR/NO COMP. ?
FEED RATE F=? / F MAX = ENT
MISCELLANEOUS FUNCTION M ?
L X+10 Y+5 RL F MAX M37
10
5
100
37
