3
| System Control
54
| NGC Chromatography Systems and ChromLab Software
Columns
Configuration
Explanation
Column
Self-explanatory when column
switching valve is absent.
Column with
column switching
valve
Used to select from up to five different
columns, bypass the columns, or
reverse the flow through the columns.
Two column
switching valves,
each with a
column attached
Used to select from up to 10 different
columns, bypass the columns, or
reverse the flow through the columns.
Three column
switching valves,
each with a
column attached
Used to select from up to 15 different
columns, bypass the columns, or
reverse the flow through the columns.
Detectors
Configuration
Explanation
Single-wavelength
UV with
conductivity
For selection of a single-wavelength UV
detector with conductivity and
temperature.
Table 3.
Fluidic Scheme Configuration Options, continued
