D-6 > Bill mechanism voltage neutral
POWER AND AUDIT CONNECTIONS
A-1 > 24VAC HOT power to interface board (or 24VDC+)
A-2 > 24VAC neutral (or 24VDC-)
D-7 > Audit 1 Voltage Input
D-8 > Neutral for ALL audit voltage inputs
D-9 > Audit 2 Voltage Input
D-10 > Audit 3 Voltage Input
D-11 > Audit 4 Voltage Input
D-12 > Audit 5 Voltage Input
> is a signal input to interface board
< is a signal output from interface board
8.3 POS4000 Function Lines/Car Wash Features
The function control lines used to start the specific car wash features purchased
by the customer are identified as "function lines 1 - 8". The use of these lines is
dependent on the specific software program in the POS4000 console. The uses
of the function lines are given in the table on the following page by the type and
number of program. To determine your POS4000 configuration, check the
system configuration report (see section 6.5.1).
