POS4000
Document Number: POS4003 104
Document Title: POS4000/V2 Operations Manual
10.2 Ribbon and Cassette Installation
In order to set the ribbon, disconnect the power source before hand. When the
printing has been continued for many hours, be careful not to touch the printer
head, as it might be hot.
1. Remove the printer cover.
2. While inserting the ribbon into the space between the print head and the
ribbon guide, press the cassette into the holder until, it clicks into place.
(Refer to fig. 4 & 5)
3. Turn the cassette ribbon knob in the direction of the arrow to take up slack in
the ribbon.
