POS4000
Document Number: POS4003 94
Document Title: POS4000/V2 Operations Manual
Make sure you return the DIP switches to normal operation mode when testing is
complete. For the normal operations, set the switches as follows:
Switch Setting
4
OFF
5 OFF
While the interface board is in the test mode, the customer buzzer will beep
approximately every 5 seconds. Once in the test mode, you select the specific
test desired by typing the following codes at the customer keypad:
CODE
TEST
10 Output relay line 1 on
20 Output relay line 2 on
30 Output relay line 3 on
40 Output relay line 4 on
50 Output relay line 5 on
60 Output relay line 6 on
70 Output relay line 7 on
80 Output relay line 8 on
90 Re-enter code relay output on
110 Code Accepted/wait relay output on
120 Enter Wash relay output on
130 Out-of-Service relay output on
140 All relay outputs on
150 Wash In-Use input status
160 Coin credit input status
170 Bill credit input status
180 Audit 1 input status
190 Audit 2 input status
210 Audit 3 input status
220 Audit 4 input status
230 Audit 5 input status
