Configuration, Code table – Lenze EVF9383 User Manual
Page 346
Configuration
Code table
8.5
l
8.5−58
EDSVF9383V EN 4.0−03/2006
IMPORTANT
Possible settings
Code
Selection
Lenze
Name
No.
C0940 Numerator
1
−32767
{1}
32767 Configuration of conversion factor
with numerator and denominator,
function block CONV1
See System
Manual
(extension)
C0941 Denominator
1
1
{1}
32767
OUT [%]
+ IN [%] @ C0940
C0941
C0942
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block CONV1
C0943 DIS: IN
−199.99
{0.01 %}
199.99 Function block CONV1
l
Display of the signal linked in
C0942
C0945 Numerator
1
−32767
{1}
32767 Configuration of conversion factor
with numerator and denominator,
function block CONV2
See System
Manual
(extension)
C0946 Denominator
1
1
{1}
32767
OUT [%]
+ IN [%] @ C0945
C0946
C0947
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block CONV2
C0948 DIS: IN
−199.99
{0.01 %}
199.99 Function block CONV2
l
Display of the signal linked in
C0947
C0950 Numerator
1
−32767
{1}
32767 Configuration of conversion factor
with numerator and denominator,
function block CONV3
See System
Manual
(extension)
C0951 Denominator
1
1
{1}
32767
OUT [%]
+ IN [rpm] @
100 %
15000 rpm
@ C0950
C0951
C0952
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block CONV3
C0953 DIS: IN
−199.99
{0.01 %}
199.99 Function block CONV3
l
Display of the signal linked in
C0952
C0955 Numerator
1
−32767
{1}
32767 Configuration of conversion factor
with numerator and denominator,
function block CONV4
See System
Manual
(extension)
C0956 Denominator
1
1
{1}
32767
OUT [%]
+ IN [rpm] @
100 %
15000 rpm
@ C0955
C0956
C0957
s
CFG: IN
1000 FIXED0%
^ Selection list 1
Configuration of analog input
signal, function block CONV4
C0958 DIS: IN
−199.99
{0.01 %}
199.99 Function block CONV4
l
Display of the signal linked in
C0957
C0960 Function
1
Function selection, function block
CURVE1
See System
Manual
(extension)
1
Function 1
Characteristic with two base
points
2
Function 2
Characteristic with three base
points
3
Function 3
Characteristic with four base
points
