Configuration
Code table
8
8.5
l
8.5−50 EDSVF9383V EN 4.0−03/2006
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0822
s
^ Selection list 2 Configuration of digital input
signals, function block AND2 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 AND2−IN1
2 CFG: IN 1000 FIXED0 AND2−IN2
3 CFG: IN 1000 FIXED0 AND2−IN3
C0823 0 1 Function block AND2
l Display of the signals linked in
C0822
See System
Manual
(extension)
1 DIS: IN AND2−IN1
2 DIS: IN AND2−IN2
3 DIS: IN AND2−IN3
C0824
s
^ Selection list 2 Configuration of digital input
signals, function block AND3 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 AND3−IN1
2 CFG: IN 1000 FIXED0 AND3−IN2
3 CFG: IN 1000 FIXED0 AND3−IN3
C0825 0 1 Function block AND3
l Display of the signals linked in
C0824
See System
Manual
(extension)
1 DIS: IN AND3−IN1
2 DIS: IN AND3−IN2
3 DIS: IN AND3−IN3
C0826
s
^ Selection list 2 Configuration of digital input
signals, function block AND4 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 AND4−IN1
2 CFG: IN 1000 FIXED0 AND4−IN2
3 CFG: IN 1000 FIXED0 AND4−IN3
C0827 0 1 Function block AND4
l Display of the signals linked in
C0826
See System
Manual
(extension)
1 DIS: IN AND4−IN1
2 DIS: IN AND4−IN2
3 DIS: IN AND4−IN3
C0828
s
^ Selection list 2 Configuration of digital input
signals, function block AND5 See System
Manual
(extension)
1 CFG: IN 1000 FIXED0 AND5−IN1
2 CFG: IN 1000 FIXED0 AND5−IN2
3 CFG: IN 1000 FIXED0 AND5−IN3
C0829 0 1 Function block AND5
l Display of the signals linked in
C0828
See System
Manual
(extension)
1 DIS: IN AND5−IN1
2 DIS: IN AND5−IN2
3 DIS: IN AND5−IN3
