Operating mode
V/f characteristic control
6.8
6.8.1
l
6.8−5 EDSVF9383V EN 7.1−04/2012
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0016 Umin boost 0.00 0.00 {0.01 %} 100.00 U
min
boost (FCODE)
l C0016 = 1 % corresponds to a
boost of 1 % of the rated motor
voltage (C0090)
l Code is freely configurable
^
6.8−4
C0021 slipcomp à −20.00 {0.01 %} 20.00 Slip compensation
à Change of C0086, C0087 or
C0089 sets C0021 to the
calculated rated slip of the
motor
l When changing over to the
vector control mode, C0021 is
set to 0
^
6.11−1
^
8.2−25
^
8.2−40
C0090
s
Mot voltage à 0 {1 V} 1000 Rated motor voltage
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
voltage in C0090
l Change of C0090 sets C0086 =
0
^ 6.6−1
1. Select "V/f characteristic control" mode (C0006 = 5, factory
adjustment).
2. Select V/f characteristic (C0014) if necessary
3. Enter the data of the motor nameplate.
4. If required, you can set a base frequency in C0015 which differs from
the rated motor frequency (C0089).
Adjustment
