Configuration
Code table
8
8.5
l
8.5−40 EDSVF9383V EN 4.0−03/2006
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0685 Function
1 1 IN1 = IN 2 Function selection, function block
CMP2
l Compare input signals at
CMP2−IN1 and CMP2−IN2
See System
Manual
(extension)
2 IN1 > IN2
3 IN1 < IN2
4 |IN1IN2|
5 |IN1IN2|
6 |IN1IN2|
C0686 Hysteresis 1.00 0.00 {0.01 %} 100.00 Hysteresis, function block CMP2
l Hysteresis for input signals
which are not stable and hence
the output oscillates
C0687 Window 1.00 0.00 {0.01 %} 100.00 Window, function block CMP2
l Set the range in which the
signal comparison is to be
apply
C0688
s
^ Selection list 1 Configuration of analog input
signal, function block CMP2
1 CFG: IN 1000 FIXED0% CMP2−IN1
2 CFG: IN 1000 FIXED0% CMP2−IN2
C0689 −199.99 {0.01 %} 199.99 Function block CMP2
l Display of the signals linked in
C0688
1 DIS: IN CMP2−IN1
2 DIS: IN CMP2−IN2
C0690 Function 1 1 IN1 = IN 2 Function selection, function block
CMP3
l Compare input signals at
CMP3−IN1 and CMP3−IN2
See System
Manual
(extension)
2 IN1 > IN2
3 IN1 < IN2
4 |IN1IN2|
5 |IN1IN2|
6 |IN1| < |IN2|
C0691 Hysteresis 1.00 0.00 {0.01 %} 100.00 Hysteresis, function block CMP3
l Hysteresis for input signals
which are not stable and hence
the output oscillates
C0692 Window 1.00 0.00 {0.01 %} 100.00 Window, function block CMP3
l Set the range in which the
signal comparison is to be
apply
C0693
s
^ Selection list 1 Configuration of analog input
signal, function block CMP3
1 CFG: IN 1000 FIXED0% CMP3−IN1
2 CFG: IN 1000 FIXED0% CMP3−IN2
C0694 −199.99 {0.01 %} 199.99 Function block CMP3
l Display of the signals linked in
C0693
1 DIS: IN CMP3−IN1
2 DIS: IN CMP3−IN2
C0700
s
CFG: IN 19523 FCODE−472/3 ^ Selection list 1 Configuration of analog input
signal, function block ANEG1
l The value at ANEG1−IN is
multiplied by −1 and output
See System
Manual
(extension)
C0701 DIS: IN −199.99 {0.01 %} 199.99 Function block ANEG1
l Display of the signal linked in
C0700
