IMPORTANT Possible settings Code
Selection Lenze Name No.
C0852 Type OUT.W2
0 Output of the signal type,
function block AIF See System
Manual
(extension)
0 analog Analog signal AIF−OUT.W2 (C0850/2) is output
to X1
1 digital 0−15 Digital signal via
bit 0 ... bit 15 FDO−00 ... FDO−15 (LOW word,
C0116/1 ... C0116/15) are output
to X1
2 low phase Low phase AIF−OUT.D1 (LOW word, C0851) is
output to X1
C0853 Type OUT.W3 0 Output of the signal type,
function block AIF
0 analog Analog signal AIF−OUT.W3 (C0850/3) is output
to X1
1 digital 16−31 Digital signal via
bit 16 ... bit 31 FDO−16 ... FDO−31 (HIGH word,
C0116/16 ... C0116/31) are output
to X1
2 high phase High phase AIF−OUT.D1 (HIGH word, C0851) is
output to X1
C0855 0 FFFF Process input words, function
block AIF−IN
l Read only
See System
Manual
(extension)
1 DIS: IN (0 ... 15) Bit 0 ... bit 15 (via byte 5 and
byte 6)
2 DIS: IN
(16 ... 31)
Bit 16 ... bit 31 (via byte 7 and
byte 8)
C0856 −199.99 {0.01 %} 199.99 Process input words, function
block AIF−IN
l Read only
l 100% = 16384
See System
Manual
(extension)
1 DIS: IN.W1 Input via byte 3 and byte 4
2 DIS: IN.W2 Input via byte 5 and byte 6
3 DIS: IN.W3 Input via byte 7 and byte 8
C0857 DIS: IN.D1 −2147483648 {1} 2147483647 32−bit phase signal, function block
AIF−IN
l Read only
l 65536 = 1 rev.
See System
Manual
(extension)
C0858 −199.99 {0.01 %} 199.99 Process output words, function
block AIF−OUT
l Display of the signals linked in
C0850
l 100% = 16384
See System
Manual
(extension)
1 DIS: OUT.W1
2 DIS: OUT.W2
3 DIS: OUT.W3
C0859 DIS: OUT.D1 −2147483648 {1} 2147483647 32−bit phase signal, function block
AIF−OUT
l Display of the signal linked in
C0851
l 1 rev. = 65536
See System
Manual
(extension)
