Configuration
Code table
8
8.5
l
8.5−9 EDSVF9383V EN 4.0−03/2006
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0082
s
Mot Rr à 0.0000 {0.0001 W} 65.5350 Motor rotor resistance
à Value is determined by motor
parameter identification from
C0087, C0088, C0089, C0090
and C0091
l Selection of a motor in C0086
sets the corresponding rotor
resistance value
^ 6.6−1
^
6.6−15
C0084
s
Mot Rs à 0.00 {0.01 m W} 100000.
00
Motor stator resistance
à Value is determined by motor
parameter identification
(C0148, C0149)
^ 6.6−1
^
6.6−15
C0085
s
Mot Lss à 0.00 {0.01 mH} 6553.50 Motor leakage inductance
à Value is determined by motor
parameter identification
(C0148, C0149)
^ 6.6−1
^
6.6−15
C0086
s
Mot type à ^ Motor selection list Motor type selection
à depending on the controller
used
l Motor selection in C0086 sets
the corresponding parameters
in C0021, C0022, C0081,
C0087, C0088, C0089, C0090,
C0091
^ 6.6−1
C0087
s
Mot speed à 50 {1 rpm} 36000 Rated motor speed
à depending on C0086
l Motor selection in C0086 set
the corresponding rated motor
speed in C0087
l Change of C0087 sets
C0086 = 0
^ 6.6−1
C0088
s
Mot current à 0.5 {0.1 A} 1000.0 Rated motor current
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
current in C0088
l Change of C0088 sets C0086 =
0
^ 6.6−1
C0089
s
Mot frequency à 10 {1 Hz} 5000 Rated motor frequency
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
frequency in C0089
l Change of C0089 sets
C0086 = 0
^ 6.6−1
C0090
s
Mot voltage à 0 {1 V} 1000 Rated motor voltage
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
voltage in C0090
l Change of C0090 sets C0086 =
0
^ 6.6−1
C0091
s
Mot cos phi à 0.50 {0.01 } 1.00 Motor cos j
à depending on C0086
l Motor selection in C0086 sets
the corresponding motor cos
j
in C0091
l Change of C0091 sets
C0086 = 0
^ 6.6−1
