Configuration
Function blocks
Master frequency processing (DFSET)
8.2
8.2.5
l
8.2−21
EDSVF9383V EN 7.1−04/2012
IMPORTANT
Possible settings
Code
Selection
Lenze
Name
No.
C0536
−32767
{1}
32767 Function block DFSET
l
Display of the signals linked in
C0521, C0522 and C0523
^
8.2−18
1 DIS: VP−DIV
2 DIS: RAT−DIV
3 DIS: A−TRIM
C0537 DIS: N−TRIM
−199.99
{0.01 %}
199.99 Function block DFSET
l
Display of the signal linked in
C0524
C0538
0
1 Function block DFSET
l
Display of the signals linked in
C0525, C0526 and C0527
1 DIS: 0−pulse
2 DIS: RESET
3 DIS: SET
C0539 DIS: IN
−6000
{1 rpm}
6000 Function block DFSET
l
Display of the signal linked in
C0520
C0546 Min inc/rev
1000 1
{1 inc.}
2147483647 Masking of the touch probe signal,
function block DFSET
l
Suppressing interference
pulses at X5/E4 (actual pulse of
touch probe signal)
l
The size of the masking
window between two actual
pulses is set
^
8.2−18
