Configuration
Code table
8
8.5
l
8.5−29 EDSVF9383V EN 4.0−03/2006
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0472 −199.99 {0.01 %} 199.99 Configuration of free control
codes for analog signals
1 FCODE analog 0.00
2 FCODE analog 0.00
3 FCODE analog 100.0
0
6 FCODE analog 0.00
... ... 0.00
20 FCODE analog 0.00
C0473 −32767 {1} 32767 Configuration of free control
codes for absolute analog signals
1 FCODE abs 1
2 FCODE abs 1
3 FCODE abs 0
... ... 0
10 FCODE abs 0
C0474 −2147483647 {1} 2147483647 Configuration of free control
codes for phase signals
l 1 rev. = 65536 inc
1 FCODE PH 0
... ... 0
5 FCODE PH 0
C0475 −16000 {1} 16000 Configuration of free control
codes for phase difference signals
l 1 rev. = 65536 inc
1 FCODE DF 0
2 FCODE DF 0
C0497 Nact filter 2.0 0.0 {0.1 ms} 50.0 Filter time constant N
act
for actual
speed value, function block
MCTRL2
l Internal filtering of the speed
signal for control
l C0497 = 0 ms: Switched off
^
8.2−40
C0510
s
CFG: IN1 50 AIN1−OUT ^ Selection list 1 Configuration of analog input
signal, function block NLIM1
l Input for analog speed setpoint
See System
Manual
(extension)
C0511 DIS: IN1 −199.99 {0.01 %} 199.99 Function block NLIM1
l Display of the input signal
configured in C0510
