Configuration
Code table
8
8.5
l
8.5−5 EDSVF9383V EN 4.0−03/2006
IMPORTANT Possible settings Code
Selection Lenze Name No.
C0026 −199.99 {0.01 %} 199.99 Free control code FCODE 26/1 and
FCODE26/2
^ 6.5−4
See System
Manual
(extension)
1 FCODE (offset) 0.00 Offset of AIN1 (X6/1, X6/2)
2 FCODE (offset) 0.00 Offset of AIN2 (X6/3, X6/4)
C0027 −199.99 {0.01 %} 199.99 Free control code FCODE 27/1 and
FCODE27/2
1 FCODE (gain) 100.0
0
Gain AIN1 (X6/1, X6/2)
l 100 % = gain 1
2 FCODE (gain) 100.0
0
Gain AIN2 (X6/3, X6/4)
l 100 % = gain 1
C0030 DFOUT const 3 0 256 inc/rev Function block DFOUT
l Setting of the constant
(increments per revolution) for
the master frequency output
X10
^ 8.2−8
1 512 inc/rev
2 1024 inc/rev
3 2048 inc/rev
4 4096 inc/rev
5 8192 inc/rev
6 16384 inc/rev
C0032 FCODE
Gearbox
1 −32767 {1} 32767 Gearbox factor − numerator of the
function block DFSET
l Freely configurable code
^
8.2−18
C0033 Gearbox
denom
1 1 {1} 32767 Gearbox factor − denominator of
the function block DFSET
^
8.2−18
C0034 Mst current 0 0 −10 V ... +10 V Voltage / current range for analog
signals at input X6/1, X6/2
l Observe jumper position of X3
^ 5.6−9
^ 6.5−4
1 4 mA ... 20 mA
2 −20 mA ... +20 mA
C0036 DC brk value 0.0 0.0 {0.1 A} − Set DC braking current
à depends on the controller
^
8.2−25
^
8.2−40
C0037 Set−value rpm 0 −36000 {1 rpm} 36000 Setpoint selection
C0038 0 {1 rpm} 36000 Suppress speed ranges, function
block NLIM1
l Speed ranges are only run
through dynamically
l Static behaviour in the
inhibited range is suppressed
See System
Manual
(extension)
1 N 1 start 0 Suppress speed range 1
2 N 1 stop 0
3 N 2 start 0 Suppress speed range 2
4 N 2 stop 0
5 N 3 start 0 Suppress speed range 3
6 N 3 stop 0
