Configuration
Code table
8.5
l
8.5−41
EDSVF9383V EN 4.0−03/2006
IMPORTANT
Possible settings
Code
Selection
Lenze
Name
No.
C0703
s
CFG: IN
19523 FCODE−472/3
^ Selection list 1
Configuration of analog input
signal, function block ANEG2
l
The value at ANEG2−IN is
multiplied by −1 and output
See System
Manual
(extension)
C0704 DIS: IN
−199.99
{0.01 %}
199.99 Function block ANEG2
l
Display of the signal linked in
C0703
C0705 Function
1
1
IN1 = IN 2
Function selection, function block
CMP4
l
Compare input signals at
CMP4−IN1 and CMP4−IN2
See System
Manual
(extension)
2
IN1 > IN2
3
IN1 < IN2
4
|IN1| = |IN2|
5
|IN1| > |IN2|
6
|IN1| < |IN2|
C0706 Hysteresis
1.00
0.00
{0.01 %}
100.00 Hysteresis, function block CMP4
l
Hysteresis for input signals
which are not stable and hence
the output oscillates
C0707 Window
1.00
0.00
{0.01 %}
100.00 Window, function block CMP4
l
Set the range in which the
signal comparison is to be
apply
C0708
s
^ Selection list 1
Configuration of analog input
signal, function block CMP4
1 CFG: IN
1000 FIXED0%
CMP4−IN1
2 CFG: IN
1000 FIXED0%
CMP4−IN2
C0709
−199.99
{0.01 %}
199.99 Function block CMP4
l
Display of the signals linked in
C0708
1 DIS: IN
CMP4−IN1
2 DIS: IN
CMP4−IN2
C0710 Function
0
Function selection, function block
TRANS1
See System
Manual
(extension)
0
Rising trans
Rising edge
1. LOW−HIGH edge at TRANS1−IN
switches TRANS1−OUT = HIGH
2. After the time has elapsed
(C0711), TRANS1−OUT switches
to LOW
1
Falling trans
Falling edge
1. HIGH−LOW edge at TRANS1−IN
switches TRANS1−OUT = HIGH
2. After the time has elapsed
(C0711), TRANS1−OUT switches
to LOW
2
Both trans
Both edges
1. LOW−HIGH− or HIGH−LOW edge
at TRANS1−IN switches
TRANS1−OUT = HIGH
2. After the time has elapsed
(C0711), TRANS1−OUT switches
to LOW
C0711 Pulse T
0.001 0.001
{0.001 s}
60.000 Pulse duration, function block
TRANS1
l
After the time has elapsed,
TRANS1−OUT switches to LOW
C0713
s
CFG: IN
1000 FIXED0
^ Selection list 2
Configuration of digital input
signal, function block TRANS1
C0714 DIS: IN
0
1 Function block TRANS1
l
Display of the signal linked in
C0713
