C0352 CAN mst
0
0
Slave
Configuration of the system bus
nodes
l
Change is effective after ˜Reset
node˜ command
1
Master
C0353
0
C0350 is the source
Source of the system bus address
1
C0354 is the source
1 CAN addr sel1
0
CAN IN1, CAN−OUT1
2 CAN addr sel2
0
CAN IN2, CAN−OUT2
3 CAN addr sel3
0
CAN IN3, CAN−OUT3
C0354
1
{1}
512 Selective system bus address
l
Individual addressing of the
system bus process data
objects
1 IN1 addr 2
129
CAN−IN1
2 OUT1 addr 2
1
CAN−OUT2
3 IN2 addr 2
257
CAN−IN2
4 OUT2 addr 2
258
CAN−OUT2
5 IN3 addr 2
385
CAN−IN3
6 OUT3 addr 2
386
CAN−OUT3
C0355
0
{1}
2047 System bus identifier
l
Read only
1 CAN−IN1 Id
2 CAN−OUT1 Id
3 CAN−IN2 Id
4 CAN−OUT2 Id
5 CAN−IN3 Id
6 CAN−OUT3 Id
C0356
0
{1 ms}
65000 System bus time settings
1 CAN boot−up
3000
Required for CAN interconnection
without master
2 OUT2 cycle
0
0 = event−controlled process data
transfer
>0 = cyclic process data transfer
3 OUT3 cycle
0
4 CAN delay
20
When the NMT state
"Operational" (after
"Pre−operational" or "Stopped")
has been reached, the delay time
˜CANdelay˜ is started. After the
delay time has e;apsed, the PDO´s
CAN−OUT2 and CAN−OUT3 are
sent for the first time.
C0357
0
{1 ms}
65000 System bus monitoring times
l
After a fault message, the CAN
objects remain in receive mode
1 CE1monit time
3000
CAN−IN1
2 CE2monit time
3000
CAN−IN2
3 CE3monit time
3000
CAN−IN3
C0358 Reset node
0
0
No function
Set the nodal reset pointof the
system bus
1
CAN reset
C0359 CAN state
0
Operational
System bus status
l
Read only
1
Pre−operational
2
Warning
3
Bus off
