Changing the assignment of the control terminals X5 and X6
Free configuration of digital input signals
6.5
6.5.1
l
6.5−1 EDSVF9383V EN 7.1−04/2012
6.5 Changing the assignment of the control terminals X5 and X6
}
Danger!
If you select a configuration in C0005, the signal assignment of
the inputs and outputs will be overwritten with the
corresponding basic assignment!
ƒ Adapt the signal assignment to your wiring!
6.5.1 Free configuration of digital input signals
ƒ Internal digital signals can be freely linked with external digital signal
sources. This serves to establish a freely configurable control of the
drive controller.
– Digital inputs X5/E1 ... X5/E5
ƒ A signal source can be linked with several targets. Ensure reasonable
linkages for not activating functions that are mutually exclusive (e. g.
linking a digital input with quick stop and DC injection braking at the
same time).
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0114 0 High active HIGH level is
active Inversion of digital input signals at
X5, function block DIGIN ^
6.5−1
See System
Manual
(extension)
1 LOW active LOW level is active
1 DIGIN1 pol 0 Terminal X5/E1
2 DIGIN2 pol 0 Terminal X5/E2
3 DIGIN3 pol 0 Terminal X5/E3
4 DIGIN4 pol 1 Terminal X5/E4
5 DIGIN5 pol 0 Terminal X5/E5
5 DIGIN6 (ST) pol 0 Terminal X5/ST
