4. The control panel (type MTR-DCI-...-H2 only)
4-24
Festo P.BE-MTR-DCI-DN-EN en 1209a
4.6 Menu command [HMI control]
To select the [Positioning] and [Settings] menu commands the
“HMI: on” setting is required. Only then is the MTR-DCI ready
to process user entries on the control panel.
When selecting the menu commands, you will be prompted to
modify the HMI setting.
You can also change the setting directly by selecting the [HMI
control] menu item.
HMI
1)
Description
on Device control is carried out manually via the control panel. The control interface of the
MTR-DCI is deactivated and control enable is set. The actual status of the FHPP control
bytes or the transmitted DS402 control word then has no effect.
When control panel control is active the drive cannot be stopped with the STOP bit.
off Device control is carried out via the control interface of the MTR-DCI.
1)
Human Machine Interface
Tab. 4/11: States [HMI control]
<- -> Select the parameter setting using the arrow
buttons.
OK Confirm the selection using the button.
ESC Pressing the
Access to the MTR-DCI via HMI and FCT can be blocked via
the Fieldbus in the following manner:
– FHPP: Bit CCON.B5, “HMI Access locked”.
HMI control
[on/off] = on?
HMI Access free
ESC
<-->
OK
