5. Commissioning

5-77

Festo P.BE-MTR-DCI-DN-EN en 1209a

Parameter identifier (PKE)

The parameter identifier contains the request or response
identifier (AK) and the parameter number (PNU).

ParID

Octet 1 (byte 3)

Octet 2 (byte 4)

Bit

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

Task

ReqID (AK)

Reserved

Parameter number (PNU)

Response

ResID (AK)

Reserved

Parameter number (PNU)

ReqID (AK)

Request identifier – task identifier (read, write, ...)

ResID (AK)

Response identifier – response identifier (transferred value, fault, ...)

Value (PNU)

Parameter Number – identifies and/or addresses the respective parameters
(see section 5.7). The task or response identifier indicates the type of task or
response (see section 5.7.2).

Tab. 5/3: Structure of parameter identifier (PKE)
