4. The control panel (type MTR-DCI-...-H2 only)
4-18
Festo P.BE-MTR-DCI-DN-EN en 1209a
4.5.2 [Settings] [Axis parameter]
Teach mode for setting the axis parameters.
• Select the following parameters to set the dimensional
reference system. Follow the instructions in chapter 5.2.4.
[Axis parameter] Description
[Zero point] Offset of the axis zero point
[Abs.min.pos] Stroke limitation: Software end position,
negative
[Abs.max.pos] Stroke limitation: Software end position, posi-
tive
[SAVE...] Save parameters in EEPROM
Tab. 4/7: [Settings] [Axis parameter] menu
<- -> Use the arrow buttons to move the axis to the
desired position.
OK Confirm the selection using the button.
ESC Pressing the
• Choose [SAVE...] to save the parameter settings. Only then
will the settings be retained even if the power supply is
switched off or if there is a power failure.
