B. Reference – Festo DeviceNet and FHPP
B-47
Festo P.BE-MTR-DCI-DN-EN en 1209a
Motor Data
FHPP 1025 1, 3 Array uint32 rw
Description Motor-specific data
Serial Number 1025 1 uint32 rw
Serial number of the motor
Time Max. Current 1025 3 uint32 rw
I 2 t time
Permissible duration for the maximum motor current (see Object 6073h).
When the I
2 t-time expires, the current will be limited automatically to the rated
motor current in order to protect the motor (nominal motor current:
PNU 1035 CI object 6075h).
The time specified is device-dependent (for MTR-DCI approx. 20 ms).
Value range: 1 ... 32767
Default: 100 (
Z 2 s)
Note: values which are too high can damage the motor!
CI 6410h 01h, 03h Record uint32 rw
DeviceNet 6Bh 01h 2Ch, 2Dh uint32 rw
