4. The control panel (type MTR-DCI-...-H2 only)
4-10
Festo P.BE-MTR-DCI-DN-EN en 1209a
Menu command Description
[DeviceNet-Diag] Bus diagnosis
– No Power /
BUS-Off Bus supply is not connected or the Fieldbus is not cor-
rectly parameterised. Connection to the master is not
possible.
– Device Oper-
ational DeviceNet is in the “Data exchange” state and is con-
nected to a master.
– Device in
Standby No connection to the DeviceNet master exists, device is
ready for operation.
– Minor Fault A recoverable fault has occurred (e.g. Timeout)
– Unrecoverable
Fault A severe, unrecoverable fault has occurred (e.g. dupli-
cate MAC ID), a reset is required to bring the device back
into operation.
Bit rate Set bit rate of the MTR-DCI:
Values:
125 k, 250k, 500 k(bit/s)
I/O data length I/O data length setting.
– 8 bytes: only for the FHPP standard (control of the
MTR-DCI is done as per the Festo Handling and Posi-
tioning Profile)
– 16 bytes: FHPP standard and FPC (additional use of
the FPC for parameterising the MTR-DCI)
MAC ID DeviceNet address of the MTR-DCI
(hexadecimal/decimal).
[SW information] MTR-DCI firmware version, e. g. V 1.20
Tab. 4/4: [Diagnostic] menu (2)
