6. Diagnosis and error display
6-4
Festo P.BE-MTR-DCI-DN-EN en 1209a
Access Brief description Advantages /
properties See...
LEDs The LEDs indicate “ready to operate”
status, positioning status, faults and
bus status. Fast
“on-the-spot”
recognition of
faults Section 6.2
Control panel on
the MTR-
DCI-...-H2 On the LCD display:
messages, warnings and faults Fast
“on-the-spot”
diagnosis Section 6.3
In the [Diagnostic] menu:
Diagnostic data, operation mode, cur-
rent positioning set, target and actual
positions, speed, and information on
communication via Fieldbus Detailed
“on-the-spot” di-
agnosis Section 4.3
Festo Configur-
ation Tool With active device connection:
– Display of the current position set,
target and actual positions, and
speed.
– Display of the operation mode,
special outputs and operating
states, and fault messages from the
connected MTR-DCI.
– Virtual LEDs in the “Device status”
window
– Display of the bus status
– Display of the diagnostic memory
Detailed diag-
nosis during com-
missioning MTR-DCI plug-in
help
FHPP/DeviceNet Diagnosis via FHPP status bytes SCON
and SPOS Simple diagnosis
via Fieldbus Section 6.4
Expanded access to diagnostic data,
e.g. diagnostic memory Detailed diag-
nosis via Fieldbus Section 6.4.2
Tab. 6/2: Diagnostic information by access
