4. The control panel (type MTR-DCI-...-H2 only)
4-16
Festo P.BE-MTR-DCI-DN-EN en 1209a
4.5 [Settings] menu
The [Settings] menu contains all functions for parameterising
the axis system and the positioning sets. Further information
on the individual menu commands is provided in the speci-
fied chapters (see Tab. 4/5).
1. From the main menu, select the [Settings] menu
2. Select a menu command.
[Settings] Description Chapter
[Axis type] Selection of the axis driven by the MTR-DCI 4.5.1
[Axis parameter] Teach mode for setting the axis parameters 4.5.2
[Homing paramet.] Setting of the homing run method and the homing speed 4.5.3
[Position set] Teach mode for programming the position set table 4.5.4
[Password edit] Set up a local 3-character password for the control panel 4.5.5
[BUS parameter] Setting Fieldbus parameters 4.5.6
Tab. 4/5: [Settings] menu
Note
The pre-set parameters take immediate effect when you
press OK . Choose [SAVE...] to save the settings
permanently to the EEPROM:
• Choose [SAVE...] to save the parameter settings. Only
then will the settings be retained even if the power
supply is switched off or if there is a power failure.
} Settings
Axis type
Axis parameter
Homing paramet.
Position set
Password edit
BUS parameter
