5. Commissioning
5-20
Festo P.BE-MTR-DCI-DN-EN en 1209a
5.2.7 Setting bus parameters
Before commissioning on DeviceNet, valid bus parameters
must be set.
Station number (MAC-ID)
– Valid station numbers: 0 ... 63.
– The invalid station number 255 is preset (control panel
display: ???).
This is to make sure that a correct address is set during
commissioning or when replacing.
Recommendation:
Assign the station numbers in ascending order. Adapt the
station numbering to the machinery infrastructure of your
plant.
Note
Station numbers can only be assigned once per Fieldbus
line.
Set the station numbers as follows:
1. Select [Settings] [Bus parameter] [MAC ID] (see also
section 4.5).
2. Press to display the current setting.
3. Use the arrow keys to set the desired bit rate.
4. Accept the setting with OK “Enter”.
The set bit rate is saved permanently and protected
against network failure.
Note
The set bit rate will not take effect until
after a power off/
on process!
} Settings
Bus parameter
MAC ID
Baud rate
500 kBd
ESC ”Menu”
EDIT ”--” OK ”Enter”
