Move position set
Position no.:
[1...31] = _?

ESC

EDIT <-->

OK

Move position set
Attention! Motor moves

ESC


START

4. The control panel (type MTR-DCI-...-H2 only)

4-12

Festo P.BE-MTR-DCI-DN-EN en 1209a

For selecting a positioning run or a homing run:

1. From the main menu, select the [Positioning] menu.

2. Select the menu command:

–

[Move position set] to test a particular positioning set
in the positioning set table (see chapter 4.4.1).

–

[Demo posit tab] to run all position set records in the
position set table one after the other.

–

[Homing] Homing run to determine the dimensional
reference system (see chapter 4.4.3).

4.4.1

[Positioning] [Move position set]

Note
Do not start a position set record until the reference
system has been defined by homing.

To test a particular position set record in the position set
table:

1. Select the position set number.

<- ->

Select the desired number using the arrow buttons.

OK

Confirm the selection using the button.

ESC

Pressing the

button cancels the action and
returns you to the higher menu level.

2. Start positioning with START .

During the positioning run, the following information is dis-
played:

–

The active positioning set, e.g. Pos 2

} Positioning

Move position set
Demo posit tab
Homing
