5. Commissioning
5-11
Festo P.BE-MTR-DCI-DN-EN en 1209a
Current limitation
1)
32 42 52 62
100 % Z
1 x nominal motor current
Motor current
Motor torque A
mNm 0.73
30 2.0
110 5.0
300 6.19
700
150 % (default) Z
1.5 x nominal motor current
Motor current
Motor torque A
mNm 1.1
46 3.0
171 7.5
460 9.29
1076
200 % Z
2 x nominal motor current
Motor current
Motor torque A
mNm 1.46
62 3.8 2)
220
7.7 2)
470
12.38
1450
1) Parameter specification in FCT: relative motor current in % of nominal current. Setting range
10...200 %.
2) Due to maximum current limiting the value does not rise further.
Tab. 5/3: Current limitation
Setting parameters
1. Select the homing parameters in the [Settings][Homing
parameter] menu (see Tab. 5/5).
2. Accept each setting with OK . The setting will then
take effect in the drive.
3. Save the parameter settings with the [SAVE] menu com-
mand.
} Settings
Homing parameter
Homing method
Velocity v_sw
Velocity v_s0
SAVE
