Example of a CSV file, which was exported to Excel:

Cell Parameter Value

Meaning

A1

Station Address 1

Station address of the PROFIBUS Slave device.

B1

Record Type

2

The Record Type is always 2.

C1 IdentNumber

7501

(0x049F) IdentNumber of the Slaves.

D1

VendorNumber 0

No Vendor number is available.

E1 VendorName

Horner

APG

Vendor name of the device.

F1 Device

HE800PBS600-001 Description of the device.

G1 Description PC_Slave

Description of the device, which is also shown in SyCon as the
name of the device.

H1

MasterAddress 1

Address of the related Master.

I1 Settings 0

The addressing mode (byte- or word addressing) and the data
format of the process data are shown. The descriptions you see in
section
Description of the Parameter
Settings.

J1 Reserved Reserved

Reserved

K1 ModulCount

2

Number of the modules of the device. For each modul the
information with data type, data size, data position and the offset
address follow. The information for
modul 1 you find in the cells L1, M1, N1, O1 and for
modul 2 in the cells P1, Q1, R1, S1.

L1

Data Size

4

The size of the modul is 4 bytes.

M1

Data Type

21

Input; Data type unsigned Integer 8

N1

Data Position

0

Output; Data type unsigned Integer 8

O1

Offset address

10

4 Byte-Modul starting with the offset address 10.

P1

Data Size

4

The size of the modul is 4 bytes.

Q1

Data Type

37

Output; Data type unsigned Integer 8

R1

Data Position

0

Data position of the second modul.

S1

Offset address

20

4 Byte-Modul starting with the offset address 10.

T1...IQ1 ...

0

The modules 3 till 59 are not used for this device and so a 0 is
shown.

Figure 58: Example of a CSV File in Excel


If two or more Slave devices are connected to the Master, these are displayed in the next lines of the
table.
