CHAPTER 1: INTRODUCTION


1.1 Scope

This manual shows how to connect and configure the Profibus Master or Slave Smartstack Modules.
HSyCon
, is an easy-to-use ‘ Windows

’-based configuration package for use with the SmartStack

COM range of fieldbus modules and Cscape or Cbreeze a windows based configuration package for
use with the OCS/ TIU product range. The software user’s guide is contained in this manual.

A basic level of understanding of Microsoft Windows technology and operation is assumed. The
manual assumes that the user is familiar with Windows 95

, Windows 98, Windows NT, Windows

2000

 or XP.


1.2 Introduction

The Smartstack Fieldbus module range require only three stages to become operational, these are:

1. Physical installation and connection.
2. Configuration of the fieldbus interface.
3. Configuration of Cscape / Cbreeze to map the fieldbus data.

The system is comprised of two separate software functions; the fieldbus interface software running
independently in the COM module and the OCS/TIU firmware running in the main module. Data and
commands are exchanged via a dual port ram interface. The configuration of the COM module is via
the RS232 serial port on the module. For correct operation, the number of registers assigned in the
OCS must match the number required by the Master or Slave module configuration.

The Smartstack module should be configured with the OCS/TIU first as otherwise it
will be held in reset and cannot be configured.


This manual is related to the following products:
