Getting Started

MAN0575-04-EN

PAGE 17 of 97

© Horner APG.This drawing is the property of Horner APG. And shall not be disclosed or reproduced except as specifically authorised.

Profibus Modules User Manual

EO 09-0009

3.5

Configuration of a SmartStack DPV1 Master to any DPV1 Slave


The following describes the steps to configure a SmartStack Profibus DPV1 Master to any Profibus
DPV1 Slave :

Action

Menu in the System Configurator

1Create a new project

File > New > PROFIBUS

2Choose Horner DPV1 Master and

provide bus address

Insert > Master

3Choose Horner DPV1 Slave and provide

bus address

Insert > Slave

4Set DPV1 parameter

Mark the Slave (left Mouse click), then
Settings > Slave Configuration
DPV1 Parameter data

5Set DPV1 buffer size (if connecting to

Horner DPV1 Slave.

Mark the Slave (left Mouse click), then
Settings > Slave Settings

6Set the bus parameter

Mark the Master (left Mouse click), then
Settings > Bus Parameters

7Set device assignment for the Master if

no automatic assignment has occurred

Mark the Master (left Mouse click), then
Settings > Device Assignment

8Set device assignment for the Slave if no

automatic assignment has occurred (if
connecting to a Horner Slave).

Mark the Slave (left Mouse click), then
Settings > Device Assignment

9Save project

File > Save

1
0

Download to the Master

Mark the Master (left Mouse click), then
Online > Download

1
1

Download to the Slave

Mark the Slave (left Mouse click), then
Online > Download

1
2

Live List

Mark the Master (left Mouse click), then
Online > Live List

1
3

Transfer user data:
Read and write data

Mark the Master (left Mouse click), then
Online > Message Monitor
Mark the Slave (left Mouse click), then
Online > Message Monitor

Table 1: Steps for Configuration of Profibus DPV1 Master to any Profibus DPV1 Slave.

Note (*1): If connecting to anything other than a Horner Slave then see the Slave manual for
configuration help.
