Getting Started

MAN0575-04-EN

PAGE 18 of 97

© Horner APG.This drawing is the property of Horner APG. And shall not be disclosed or reproduced except as specifically authorised.

Profibus Modules User Manual

EO 09-0009

3.6

Configuration a SmartStack Profibus DPV1 Slave to any Profibus DPV1 Master


The following table describes the steps to configure a SmartStack Profibus DPV1 Slave to any
Profibus DPV1 Master:

Action

Menu in the System Configurator

1Create a new project

File > New > PROFIBUS

2Choose Horner DPV1 Master and provide bus address

(*1)

Insert > Master

3Choose Horner DPV1 Slave and provide bus address

Insert > Slave

4Set DPV1 parameter

Mark the Slave (left Mouse click), then
Settings > Slave Configuration
DPV1 Parameter data

5Set DPV1 buffer size

Mark the Slave (left Mouse click), then
Settings > Slave Settings

6Set device assignment if no automatic assignment has

occurred

Mark the Slave (left Mouse click), then
Settings > Device Assignment

7Save project

File > Save

8Download

Mark the Slave (left Mouse click), then
Online > Download

9Transfer user data:

Read and write data

Mark the Slave (left Mouse click), then
Online > Message Monitor

Figure 3.5. Steps for Configuration a SmartStack Profibus DPV1 Slave to any Profibus DPV1

Master


Note (*1)
: Insert a SmartStack Profibus DPV1 Master. This Master is a placeholder and it is not
necessary to match the connected Master.
